DFMEA培训资料.ppt

2023/3/16,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,内容,课程目的什么是FMEAFMEA的起源为什么要用FMEAFMEA的分类什么时候用FMEA特殊特性在FMEA怎样做FMEA怎样降低过程的风险（RPN）FMEA中常见的问题缺陷树分析和FMEA,DFMEA培训资料,课程目的,明白FMEA的角色和作用明白过程FMEA（DFMEA）的概念和技术以及怎样应用明白设计FMEA（DFMEA）的概念了解缺陷树分析（FTA）了解零缺陷质量控制和防错法的概念以及他们对FMEA的含意,DFMEA培训资料,什么是FMEA?,潜在的失效模式及其效应分析潜在的 而不只是现有的失效模式 研究的对象效应（后果）失效模式的影响,DFMEA培训资料,是一个前期质量策划的工具用来评估潜在的失效模式和失效模式产生的原因,区分失效的优先次序。根据失效模式的风险和所采取的行动来消灭和减少发生的几率。提供一个方法用来分析制程并持续改进。FMEA必须与别的质量工具结合才能更好的解决问题，如DOE，SPC，因果分析图等FMEA 的焦点是通过问题的前摄来达到预防的目的而不是解决现有的问题。,什么是FMEA?,DFMEA培训资料,FMEA的分类,三种类型的 FMEA 系统FMEA(SFMEA)设计FMEA(DFMEA)过程FMEA(PFMEA),DFMEA培训资料,FMEA的起源,FMECA（Failure Mode Effects and Criticality Analysis）失效模式的后果及其危险程度分析起源于20世纪50年代 航空航天业以及美国军工业分类和等级 目标是预防致命的问题的发生特别强调安全问题FMEA失效模式及其效应分析-1960s 和 70s首先使用FMEA的是可靠性工程师,DFMEA培训资料,为什么要用FMEA?,DFMEA培训资料,汽车行业QS9000 和TS16949APQP手册过程安全管理行动(PSM)（美国职业安全健康局）CFR 1910.119999999 列出PFMEA是六种方法中的一种用来评估危险性FDA（美国药品管理局）-GMPs设计FMEA是其中一个工具用来评估一个新的设计。ISO 9001预防行动的要求.FMEA是一个很好的持续改进的工具来符合这个条款的要求。ISO14000可以用来评估有害物质的风险。,为什么用FMEA？,DFMEA培训资料,一个早期的 FMEA,DFMEA培训资料,SFMEA从概念开发的开始阶段到正式的设计方案开始前。用于评估系统的失效风险DFMEA从概念开发的后期阶段开始到设计方案完成。用于评估设计的失效风险PFMEA从设计开发完成开始到产品的试产前。用于评估制造过程的失效风险。,什么时候做FMEA？,DFMEA培训资料,FMEA 的时间表,DFMEA:从过程的早期开始.设计的草图完成后，在任何的工具设计开始前。PFMEA:从过程开发的早期阶段开始，已经大致确定了过程的初步方案。应在量产的方案确定之前或量产批准前。,概念设计 设计 设计完成 试生产 产品和过程批准 量产开始,PFMEA,DFMEA,SFMEA,DFMEA培训资料,三种 FMEA之间的关系,SFMEA,PFMEA,DFMEA,DFMEA培训资料,三种 FMEA之间的关系,DFMEA培训资料,DFMEA培训资料,典型的汽车产品发展的三步曲,DFMEA培训资料,典型的汽车产品发展的三步曲,DFMEA培训资料,典型的汽车产品发展的三步曲,DFMEA培训资料,Some Key FMEA Terms,Customer InputTeam-Team Selection(Cross-Functional)Ranking-Ranking of DecisionsRisk Priority Assessment Design Process Production Process,DFMEA培训资料,Automotive Acronyms:,AIAG:Automotive Industry Action GroupAPQP:Advanced Product Quality PlanningDFMEA:Design Failure Mode and Effects AnalysisDOE:Design of ExperimentsFMA:Failure Modes AnalysisFMEA:Failure Mode and Effects AnalysisKCC:Key Control CharacteristicKPC:Key Product CharacteristicPFMEA:Process Failure Mode and Effects AnalysisPPAP:Production Part Approval ProcessPSW:Product Submission WarrantQFD:Quality Function Deployment,DFMEA培训资料,Automotive Madness,DFMEA培训资料,特殊特性,产品的特殊特性尺寸，性能参数。影响产品的功能，可靠性，寿命，耐用性，安全性可能影响法律法规的符合性一般由客户指定，图纸上用特殊的符号标出。如“”，“”等。,DFMEA培训资料,特殊特性,过程的特殊特性可能产品的影响产品的功能，可靠性，寿命，耐用性，安全性，或可能影响法律法规的符合性或产品后续生产过程的制造过程参数。一般通过FMEA评估产生，由制造商自己指定。产品和过程的特殊特性都应当包含在控制计划中。,DFMEA培训资料,Characteristics I,DFMEA培训资料,Characteristics II,DFMEA培训资料,Characteristics III,DFMEA培训资料,Characteristics IV,DFMEA培训资料,Characteristics V,DFMEA培训资料,怎样用FMEA评估过程的风险？,什么是失效模式一般指的产品的失效（缺陷）。这些缺陷可能是功能，装配，外形方面的问题，对客户满意度有不同程度的影响。注意：不一定是外部客户，有可能指的是内部客户。,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,怎样用FMEA评估过程的风险？,失效模式的风险度一般用 RPN（风险度序数）来表示过程的风险度，RPN最小为1，最大是1000。RPN越大，被评估过程的风险越大。,DFMEA培训资料,DFMEA培训资料,怎样用FMEA评估过程的风险？,失效模式的严重度（S）一般用S（严重度）来表示产品的缺陷对最终使用，或下道工序，以及客户满意度的影响程度。D最小为1，最大是10。D越大，产品的缺陷越严重，缺陷造成的后果 越严重。,DFMEA培训资料,怎样用FMEA评估过程的风险？,失效模式的发生频率（O）用 O（发生频率）来表示产品的缺陷的可能性。O最小为1，最大是10。O越大，产品的缺陷发生的可能性越大。,DFMEA培训资料,怎样用FMEA评估过程的风险？,失效模式的不可探测度（D）用 D（不可探测度）来表示产品的缺陷的被发现的可能性。D最小为1，最大是10。D越大，产品的缺陷越难以被探测到的可能性越小。,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,怎样做PFMEA？,成立一个跨部门的小组制造（工艺）工程师设备工程师设计工程师品质工程师生产工程师/主管可靠性工程师工业工程师等。在开始FMEA前，把小组的人员先写在FMEA表格的上边。,一般是组长,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,怎样做PFMEA？,2.定义所涉及的产品的特殊特性：客户图纸规格书等。必要时应与客户沟通，以确保领会客户的要求。,DFMEA培训资料,DFMEA培训资料,练习 1,指定一个产品，并定义产品的特殊特性。,DFMEA培训资料,怎样做PFMEA？,3.画出产品的生产流程图.,DFMEA培训资料,PROCESS FLOW DOCUMENT,Flow CHART,Preliminary ProcessDescription of anticipated manufacturing processdeveloped from preliminary bill of material andproduct/process assumptions.(P10#1.10 APQP)&(P104 APQP)Flow DIAGRAM,ProcessDepicts the flow of materials through the process,including any rework or repair operations.(P50 PPAP),DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,How To Use The Flow Chart Use to help determine who should be involved by identifying all the work areas in a process Use as a job aid to remind people about process standards Use as a check list to collect data on where problems occur Use to investigate why rework is occurring at a certain place in the process Use the ideal process flow chart data to communicate your proposed solution,DFMEA培训资料,Flow Chart Tips If a process step or box has two output arrows,consider whether a decision box is needed Remember that the people closest to the work know it best.Make sure people are involved in developing the flow chart Software packages make flow chart production easy.,DFMEA培训资料,怎样做PFMEA？,4.把出对产品的特殊特性有影响的过程先标出来，这些过程应当优先评估。5。把对下道工序有影响的工序标出来，这些过程也应当优先评估。6。把每道工序的功能写下来。思考：想一下，为什么？,DFMEA培训资料,练习 2,画出产品的生产流程图.把出对产品的特殊特性有影响的过程先标出来，这些过程应当优先评估。把对下道工序有影响的工序标出来，这些过程也应当优先评估。把每道工序的功能写下来。,DFMEA培训资料,怎样做PFMEA？,7.列出每一个过程的失效模式，即每一个过程可能产生的缺陷。注意：是可能发生的缺陷，是潜在的，不一定是已有发生的。8.评估每一个缺陷可能造成的后果，根据FMEA的规则对后果进行评分。即S的分数。,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,FMEA Rating of S,O,D,DFMEA培训资料,DFMEA培训资料,DFMEA培训资料,Recommended Actions When the failure modes have been ranked by their RPN,corrective actions should be first directed at the highest ranked concerns and critical items identified.The intent of any recommended action is to reduce one or more(or all)of the occurrence,severity and/or detection rankings.Only a design revision can bring about a reduction in the severity ranking.If no actions are recommended for a specific cause,this should be indicated.A reduction in the occurrence ranking can only be effected by removing or controlling one or more of the causes of the failure mode through a design revision.An increase in design verification actions will result in a reduction in the detection ranking ONLY.Design FMEA doesnt rely on process controls to overcome potential weaknesses in the design;however,it does take technical and physical limitations of a process into consideration(Design Rules),DFMEA培训资料,DFMEA培训资料,The Process Potential FMEA Identifies potential product-related failure modes Assesses the potential customer effects of the failures Identifies the potential internal and external manufacturing or assembly process causes and identifies process variables on which to focus controls for occurrence reduction and/or detection of the failure condition(s)Develops ranked list of potential failure modes,thus establishing a priority system for corrective action considerations Documents the results of the manufacturing or assembly process,DFMEA培训资料,Process Potential FMEA A Process Potential FMEA is an analytical tool utilized by a Process FMEA team as a means to ensure potential failure modes and their associated causes are identified,considered and addressed.Teams should be run by the owner of the process or someone who understands the process well.Defines reasons for rejection at specific operations.In preparation for the FMEA,the assumption should be made that the incoming parts and materials are correct.A comparison of similar processes and a review of customer claims relating to similar components is a recommended starting point.A knowledge of the purpose of the design is necessary.It can be cause-associated with a potential failure mode in asubsequent operation or an effect associated with a potential failure in a previous operation.Each potential failure mode for the particular operation should be listed in terms of a part or process characteristic.,DFMEA培训资料,DFMEA培训资料,Process FMEA FociCustomers include:End User Next Manufacturing or Process Step Process Engineers Assembly Engineers Repair Functions Test Engineers Product Analysis Dealership or other Sales Outlet,DFMEA培训资料,Process FMEA Benefits As a systematic approach,the Process Potential FMEA parallels and formalizes the mental discipline that an engineer goes through in any manufacturing planning process.The Process Potential FMEA identifies potential product related process failure modes.The Process Potential FMEA assesses the potential customer effects of the failures.The Process Potential FMEA identifies potential manufacturing and/or assembly process causes.The Process Potential FMEA identifies significant process variables to focus controls for occurrence reduction and detection of failure conditions.The Process Potential FMEA develops a list of potential failure modes ranked according to their affect on the customer,thus establishing a priority system for corrective and preventive action considerations.,DFMEA培训资料,More Process FMEA Considerations The Process FMEA is a living document.The Process FMEA should be continually updated as changes occur throughout all phases of product development and on into and through to the end of production.The Process FMEA should begin with a flow chart of the processes-from receiving through shipping and warehousing.The Potential Failure Modes/Causes which can occur during manufacturing or assembly process are covered by the Process FMEA but some information(severity rankings,identification of some effects)may come from the Design FMEA.A reduction in occurrence ranking can only be achieved byimplementing a process change that controls or eliminatesone or more causes of the failure mode.,DFMEA培训资料,DFMEA培训资料,General Rating of S,O,D,DFMEA培训资料,1.Omitted processing2.Processing errors3.Errors setting up work pieces4.Missing parts5.Wrong parts6.Processing wrong work piece7.Mis-operation8.Adjustment error9.Equipment not set up properly10.Tools and/or fixtures improperly prepared,11.Poor control procedures12.Improper equipmentmaintenance13.Bad recipe14.Fatigue15.Lack of Safety16.Hardware failure17.Failure to enforce controls18.Environment19.Stress connections20.Poor FMEA(s).,Process Failure Causes,DFMEA培训资料,1.Standardized work instructions/procedures2.Fixtures and jigs3.Mechanical interference interfaces4.Mechanical counters5.Mechanical sensors6.Electrical/Electronic sensors7.Job sheets or Process packages8.Bar coding with software integration and control9.Marking10.Training and related educational safeguards11.Visual Checks12.Gage studies13.Preventive maintenance14.Automation(Real Time Control),Controls can beprocess controls such as fixture foolproofing or SPC,or can be post-process inspection/testing.,Inspection/testingmay occur at thesubject operation orat subsequentoperation(s)that candetect the subjectfailure mode.,Process Control Examples,DFMEA培训资料,Typical Process Documents SPC records Visual aides Work instructions Inspection instructions/records Equipment operating instructions Training records Traceability records,DFMEA培训资料,Recommended Actions Corrective Action should be first directed at the highest concerns as rank ordered by RPN.The intent of any recommended action is to reduce the occurrence,severity and/or detection rankings.If no actions are recommended for a specific cause,then this should be indicated.Only a design revision can bring about a reduction in the severity ranking.To reduce the probability of occurrence,process and/or specification revisions are required.To increase the probability of detection,process control and/or inspection changes are required.Improving detection controls is typically costly.The emphasis should be placed on preventing,rather than detecting,defects.,DFMEA培训资料,Fault-tree analysis is a deductive process Especially useful for Analyzing failures,when the causes of failures have not been identified Reliability engineering Tool Motor Failure,The Role and Function of FTA,Motor Failure,DFMEA培训资料,DFMEA培训资料,Fault Tree Symbols The EllipseThe top event,the ellipse,contains the description of the system-level fault or undesired event.This symbol appears at the head or top of the tree and is included only once in any tree.The input to the ellipse is from a logic gate.The RectangleThe fault event,the rectangle,contains a brief description of a lower-level fault.This description should be short without being vague.Fault events appearthroughout the tree and have both their input and output from a logic gate.Logic GatesLogic Gate inputs and outputs,except for the Inhibit Gate,which is addressedbelow,have similar connections.The output from a logic gate is to any faultevent block or to a Transfer Out function.The input is from any fault event block or from a Transfer In function.The AND Gate is the logic gate in which the output occurs only if all inputs exist.The OR Gate is the logic gate in which the output occurs only if one or more of the input events occur.,DFMEA培训资料,Fault Tree Fundamentals1.Defining the Undesired Event(s)(Major Fault(s)a.The undesired event is most often the fault which,upon occurrence,results in complete failure of the system,the failure of a back-up system,degradation,or an undetected failure.This is considered catastrophic failure.The major fault is a failure which causes loss of availability through the degradation or systemshut-down and/or poses a safety hazard to operators and/or maintenancepersonnel.The undesired event,however,may be an unusual failure at a subsystem level,the root cause of which is unknown.Any observable event may be chosen as the“undesired event”.The analyst must recognize that the FTA will not identify failures unrelated to the chosen event.b.To define the undesired event,the normal system operation and environment must be known in order to allow the analysis to show the undesired event as a failure.When defining the undesired event,care must be taken to prevent the range of the faults from becoming too broad.For example,“Failure to complete trip”,for an automobile,is not specific enough to allow for ease of analysis.This is because failure could vary from an air conditioning fault,which caused discomfort,to loss of engine power,which caused loss of mobility.Both faults could be considered failure;however,loss of mobility is obviously a much more severe fault than losing air conditioning.,DFMEA培训资料,Fault Tree Fundamentals(Continued 1)2.Defining Types of FaultsFaults fall into two basic categories:operational and component.Operation FaultThe operational fault is one which occurs when a component is operating as it was designed to,but at an inappropriate time or place.An example is a failure of a control valve to close or to interrupt the introduction of a reactant into a chemical process due to an inappropriate signal from another device.Component FaultThe component fault can be further divided into two sub-categories:primary and secondary.A Primary component fault occurs when a component fails tofunction in its intended environment.Example:A radar unit designed for use in aircraft which fails due to vibration.A Secondary component failure occurs when a component fails to function in an environment other than the environment for which it is intended.Example:A radar unit designed for a cargo aircraft fails in a fighter aircraft due to vibration.,DFMEA培训资料,Fault Tree Fundamentals(Continued 2)3.Comparison of Fault Occurrence and Fault ExistenceThe term Fault Occurrence refers to the fact that an undesired event has taken place and may or may not still exist.Fault Existence,howev
