油水分离器操作说明书天津今誉源科技发展有限公司是集研发和生产气体顶压设备，污水提升设备，油脂分离器，浮油收集器等先进环保设备于一体的优秀企业。一、概述SummarizeYF型油水分离组合装置是由中国船舶工业忌公司第九设计研究院针对陆域含油废水特性设计的一种新颖油水分离装置，采用了多项油水分离的最新成果，可以适用于不含表面活性剂的各类机油、柴油、润滑油、动植物油等油品的含油废水处理，具有结构紧凑,操作管理维修简便,能耗低，分离效率高等特点。处理后出水的含油量能有效地控制在5mgL以下,可直接排放或适当回用,分离出的废油也可回收利用，因此在节能、节水、保护环境等方面均显示出良好的技术经济效益。YSFtyPeoil-waterseparatorcombiner,oneoflatestoil-waterseparatingdevice,whichhasbeendesignedinthelightofoiledwastewater,scharacteristicbyNo.9DesignandResearchInstituteofShipIndustryParentCompanyofChinaandhasadoptedmanylatestoil-waterseparatingresearchresults,issuitformanykindsofoiledwastewatertreatmentsuchasmachineoil,dieseloil,lubricatingoilandtallow,vegetabletallow.Andithastheadvantageofcompactstructure,easyoperationandmaintenance,lowconsumption,highseparatingeffectetc.So,theoilpercentageofeffluentbytreatmentcanbeuptodown5mgLeffectivelyandmaydirectlydischargeorreuseproperly,also,theremovaloilcanreuse.Therebyabove,itisindicativethatithasupstandingtechnicaleconomicalbenefitsataspectsofenergyandwatersaving,environmentprotection.本装置采用简便、低运行耗费的全物理法处理工艺。Ithadadoptedtruephysicaltreatmentprocess,whichiseasy,andlowenergyconsumption.处理装置将一至三级处理工艺组合成一钢制圆筒形整体结构，与螺杆泵，油水层析槽及电器控制盒组合成具有完整功能的处理装置。Thecompletedeviceisonecombinerfromthefirstleveltreatmenttothesecondintoonecylindersteelstructurewithscrewpump,oil-waterseparatingtroughandelectriccontrolbox.处理工艺充分利用了重力分离特性，不同分离材料的浸润特性等有利于提高油水分离率的物理特性，对于工况较复杂的各种机械混合类含水量油废水具有广泛的适应能力。Theprocesswillmakeallbestuseofgravityseparatingcharacteristic,differentsoakageofdifferentmaterial,coarsegrain,adsorptionaggregationtoincreaseoil-waterseparatingcoefficient,andevenfordifferentcomplicatedoilnesswastewater,itstillcanbedealtwith.操作说明：二、操作说明：Operationmanual1、检杳：装置启动前应先检杳各阀门阀位，螺杆泵及电气控制工况是否符合要求。Check:beforestarting,checkwhetherallvalves,screwpumpsandelectriccontrolarerightornot.2、运行准备：Runningprepare2.1新装置第一次起动：将螺杆泵进水管转接清水池（水槽及水箱），开启排油阀，排气阀后启动螺杆泵，逐级进液，排气，直至相应筒体满流后关闭相应的排油、排气阀，各级全部满流后继续运行半小时，一般采用循环运行方式，即运行也水可返回水池（槽或箱）Firststarting:Turntheinletofscrewpumpstoclearingwaterreservoir,turnontheoildischargevalve,airexhaustvalve,then,turnonscrewpumps,influententersandairescapesstepbystep,untilthecylinderisfullandallunitsworkhalfanhour,wejustshutthendown.2.2TS启动：先将螺杆泵进出水管转接清水池运行半小时，并逐级气至满流。Commonstarting:firstturnscrewpumpstoclearingwaterreservoirandletitrun30mins,andexhauststepbystepuptofull-flow.2.3含油废水处理运行：处理装置经清水运行半小时，并逐级排气至满流后，可将进水管转入废水池进入处理运行，同时根据含油废水的含油浓度确定排油周期，排油只需开启排油阀，并通过排油观察控制开启时间，一般条件下，每班只需开启一次小时一次）Oilnesswastewaterprocessingrunning:Afterdoing（8arunningwithclearingwaterhalfanhourandstepbystepexhaustairtofull-flow,weturnthewastewaterovertotheseweragepooltotreatandmakethedischargeperiodofoilinthelightofoilconcentration.Andonlyturnontheoildischargewhenitisnecessaryandobservethestarttime,generallyspeaking,onlyoneforoneshifti.e.8hrsonce.2.4停车：结束运行前应将螺杆泵进水管转入清水池（槽或箱）运行半小时，然后再停泵,停泵时就关闭所有阀门，fJ筒体的;Iot状态。Shutdown:beforerunningover,turntheinletofscrewpumptoclearingwaterreservoirandmakeitwork30mins,then,shutitdown;whenthepumpsareoff,allvalvesareoffandthecylinderisfull-flow.装置特点：三、装置特点：ApparatusFeatures1、由于陆域含油废水的处理工艺一般总先利用含油废水池进行沉砂、隔油预处理，可大大降低进入处理装置的含油废水浓度，因此处理装置的排油周期可以较长，一班排油一次就可以了。Becausegenerallyfirstdothesettlinggritandskimmingoiltreatmentforfieldoilnesswastewater,whichcandecreasetheoilconcentrationgreatlybeforetreating,sothisoildischargeperiodofequipmentislongalitter,wecanselectonceperoneshift.2、设置专用贮油器贮存废油，以便于排油操作和进一步油水分离。Equipwithspecialoilstoragetankforremovaloiltoseparatethemfurther.3、本装置采用组装结构，结构紧凑，便于运输、安装及保养。Thisequipmentadoptscombinedstructure,whichiscompactforShifDpingJnstaIIationandmaintenance.注意事项：四、注意事项：Notices1、本装置应在清水满流的四下启动，因此启动和停车要清水运行半小时，并在此过程中逐级排气.Starttheequipmentonconditionoffull-flow,andbeforeandafterbedonethoserunningwithclearingwaterrespectively,startupandshutdown,andmeanwhileexhauststepbystep.2、含油废水应经过澄清、隔油设施预处理，泵前应设置机械过滤器。Placemechanismfilterbeforepump,andthewastewaterwillgothroughclarifierandoilseparator.3、应注意含油废水池液位，以免抽空后磁体空转发热损坏,必要时可设置液位报警信号或液位联动可自控系统。Observethewaterlevel,avoidingthemagnetfrombeingemptyanddamaging,andwecansetdownonelevelalarmorlevellinkingautomaticsystem天津今誉源科技发展有限公司山东办事处
